Description
- ECG Interpretation
- 12SL Adult and Pediatric ECG Analysis Program
- Computerized Measurements
- 12SL? Adult and Pediatric ECG Analysis Program
Optional - PHI-RES & HI-RES Late Potential Analysis
- Additional ECG Function
- Vectorcardiography
- ECG Analysis Frequency
- 500 samples/second (sps)
- ECG Storage
- 150 typical
- 200 ECGs maximum on removable media (1.44 MB, 3.5diskette)
- Digital Sampling Rate
- 4000 samples / second / channe
- Pre-Acquisition
- Provides 10 seconds of instantaneous ECG acquisition
- AC Differential
- 10 mV DC offset: ?320 mV
Resolution
- 4.88 ?V/LSB @ 500 sps
- Frequency Response 3 dB @ 0.01 to 150 Hz Common Mode Rejection >140 dB (123 dB with AC filter disabled)
- Input Impedance
- >10M@ 10 Hz, defibrillator protected Patient Leakage <10 ?A
- Pace Detect
- Orthogonal LA, LL and V6; 750 V @ 50 s
- Special Acquisition Functions
- Disconnected lead detection
- Electrode impedance
- Excessive AC noise
- Baseline wander and muscle tremor messages
- Heart Rate Meter 30 to 300 BPM ? 10% or 5 BPM whichever is greater. Heart rates outside this range will not be displayed
Display
- Display Type 264 mm (10.4 in) diagonal graphics backlit AM LCD
Display Resolution 640 x 480 pixels with waveform enhancement
Display Data
- Heart rate
- Patient name
- ID
- Clock
- Waveforms
- Lead labels
- Speed
- Gain and filter settings
- Warning messages
- Prompts and help messages
